| DT-PJ-1.5 | DT-PJ-2.2 | DT-PJ-3.0 | DT-PJ-4.0 | DT-PJ-5.5 | DT-PJ-7.5 | DT-PJ-11 | DT-PJ-15 | |
|---|---|---|---|---|---|---|---|---|
| DT-PJ-1.5A | DT-PJ-2.2A | DT-PJ-3.0A | DT-PJ-4.0A | DT-PJ-5.5A | DT-PJ-7.5A | DT-PJ-11A | DT-PJ-15A | |
| DT-PJ-1.5B | DT-PJ-2.2B | DT-PJ-3.0B | DT-PJ-4.0B | DT-PJ-5.5B | DT-PJ-7.5B | DT-PJ-11B | DT-PJ-15B | |
| Voltage(V/Hz) | 380/50 | |||||||
| Power(kW/(HP)) | 1.5/2.0 | 2.2/3.0 | 3.0/4.0 | 4.0/5.5 | 5.5/7.5 | 7.5/10 | 11/15 | 15/20 |
| Starting current (A) | 25 | 40 | 50 | 56 | 65 | 95 | 120 | 150 |
| Rated current(A) | 3.2 | 4.4 | 6 | 7.7 | 10.5 | 14.1 | 20.5 | 28 |
| Max airflow(m³/h) | 1500 | 2200 | 3000 | 4000 | 5300 | 7100 | 9000 | 11000 |
| Filter area(m²) | 11 | 22 | 22 | 44 | 44 | 66 | 99 | 99 |
| Filter efficiency | >99% | |||||||
| Dust container capacity (L) | According to customers'demand | |||||||
| Noise dB(A) | 73±2 | 75±2 | 76±2 | 76±2 | 78±2 | 79±2 | 80±2 | 81±2 |
| Filter cleaning method | Pulse jet、Automatic discharge(A)、Large capacity collection bin(B) | |||||||
| Ability of discharge(L/min) | 48 | 96 | 96 | 96 | 96 | 240 | 240 | 240 |
| Air inlet Dia. (mm) | Ø150 | Ø200 | Ø250 | Ø300 | Ø350 | Ø350 | Ø350 | Ø350 |
