Designed for continuous-duty suction of large mixed particles and chips, this model is optimized for three-phase operation and performs reliably in environments with both heavy and fine dust. Typical applications include metal processing (grinding, cutting, drilling), PCB manufacturing (cutting, drilling, routing), textile cleaning, and general machine cleaning.
Three-phase industrial vacuum cleaner delivering high pressure for efficient cleaning performance.
Customizable voltage options to meet different regional power requirements.
Single-phase configuration available for power ratings up to 2.2 kW.
Integrated filter cleaning system for easy maintenance and extended filter life.
Maintenance-free, high-performance turbine motor designed for 24/7 continuous operation.
Easy-to-clean dust container for fast and hassle-free servicing.
| DV-22C | DV-40C | |
|---|---|---|
| Voltage(V/Hz) | 380/50 | 380/50 |
| Power(kW) | 2.2 | 4.0 |
| Starting current (A) | 30 | 60 |
| Rated current (A) | 5.6 | 9 |
| Max airflow(m³/h) | 210 | 400 |
| Max vacuum(kPa) | 19.6 | 20.5 |
| Noise dB(A) | 74±2 | 75±2 |
| Air inlet Dia. (mm) | Ø50 | |
| Filter area(m²) | 1.5 | |
| Filter efficiency | >99% | |
| Capacity of collection barrel(L) | 65 | |
| Dimensions[L×W×H](mm) | 1080*650*1300 | |
| Weight(kg) | 90 | 100 |
