Designed for three-phase working conditions,this system is ideal for continuous operation in environments with heavy and fine dust.Applications include metal processing(grinding,cutting,drilling,and similar tasks,PCB manufacturing (cutting,drilling,routing),and machine cleaning.
Ex his quidam aeternitati se commendari posse per statuas aestimantes eas ardenter adfectant quasi plus praemii de figmentis aereis sensu carentibus adepturi, quam ex conscientia honeste recteque factorum, easque auro curant inbracteari, quod Acilio Glabrioni delatum est primo, cum consiliis armisque regem superasset Antiochum. quam autem sit pulchrum exigua haec spernentem et minima ad ascensus verae gloriae tendere longos et arduos, ut memorat vates Ascraeus, Censorius Cato monstravit. qui interrogatus quam ob rem inter multos... statuam non haberet malo inquit ambigere bonos quam ob rem id non meruerim, quam quod est gravius cur inpetraverim mussitare.
The entire system (equipment, motor, and control cabinet) is explosion-proof, eliminating ignition sources at the root.
Specialized filter media and anti-static measures prevent static electricity accumulation and equipment failure caused by conductive dust.
The solution considers compatibility with low-humidity dry room environments to avoid compromising battery production quality.
Customizable voltage options, including single-phase for power ≤2.2KW.
Two filtration options to accommodate varying filtration accuracy needs.
Built-in filter cleaning device for hassle-free maintenance.
Maintenance-free turbine motor designed for continuous 24-hour operation.
Integrated pressure gauge for real-time filter clogging detection.
Easy-to-clean dust container for streamlined disposal.
Paphius quin etiam et Cornelius senatores, ambo venenorum artibus pravis se polluisse confessi, eodem pronuntiante
We offer 24/7 online support to assist with all your Power Supply needs.
Conductive dust intrusion into precision equipment causes frequent breakdowns and downtime
Strict environmental protection regulations and safety production access requirements.
| DV-HD-22 | DV-HD-30 | DV-HD-40 | DV-HD-55 | DV-HD-75 | |
|---|---|---|---|---|---|
| Voltage(V/Hz) | 380/50 | ||||
| Power(kW) | 2.2 | 3.0 | 4.0 | 5.5 | 7.5 |
| Starting current(A) | 30 | 40 | 60 | 85 | 100 |
| Rated current(A) | 5.6 | 7.2 | 9 | 12.9 | 16.7 |
| Max air flow(m³/h) | 245 | 285 | 385 | 432 | 600 |
| Max vacuum(kPa) | 19.6 | 20.6 | 21.6 | 21.6 | 22.6 |
| Noise dB(A) | 72±2 | 74±2 | 75±2 | 76±2 | 78±2 |
| Dia.air inlet(mm) | Ø50 | ||||
| Filter area(m²) | 3.0 | ||||
| Filter efficiency | >99% | ||||
| Capacity of collection barrel(L) | 100 | ||||
| Dimensions[L×W×H](mm) | 1360*670*1525 | ||||
| Weight(kg/(lb)) | 132 | 140 | 148 | 171 | 174 |
