Medium/Large Industrial Dust Collectors

By introducing inert powder into the dust collector to reduce or eliminate the concentration of oxygen. This prevents the formation of a combustible mixture between the flammable dust and oxygen, rendering any potential ignition source incapable of triggering an explosion.

Get a Quote Brochure

Dust Removal is Crucial for Manufacturing

Ex his quidam aeternitati se commendari posse per statuas aestimantes eas ardenter adfectant quasi plus praemii de figmentis aereis sensu carentibus adepturi, quam ex conscientia honeste recteque factorum, easque auro curant inbracteari, quod Acilio Glabrioni delatum est primo, cum consiliis armisque regem superasset Antiochum. quam autem sit pulchrum exigua haec spernentem et minima ad ascensus verae gloriae tendere longos et arduos, ut memorat vates Ascraeus, Censorius Cato monstravit. qui interrogatus quam ob rem inter multos... statuam non haberet malo inquit ambigere bonos quam ob rem id non meruerim, quam quod est gravius cur inpetraverim mussitare.

Intrinsically Safe Design

The entire system (equipment, motor, and control cabinet) is explosion-proof, eliminating ignition sources at the root.
Optimization for Conductive Dust

Specialized filter media and anti-static measures prevent static electricity accumulation and equipment failure caused by conductive dust.
Compatibility with Dry Environments

The solution considers compatibility with low-humidity dry room environments to avoid compromising battery production quality.

feature

Take a Closer Look

High Airflow

Equipped with a high-airflow dust extraction fan and large-surface filter cartridges specifically engineered for high-dust environments.
Pulse-Jet Cleaning

Integrated pulse-jet cleaning system with Venturi tubes to optimize reverse airflow efficiency.
Stable Operation

Ensures stable operation with powerful suction, featuring a filter pressure differential alarm for proactive maintenance.
Slide-In Cartridge

Horizontal slide-in cartridge design enables effortless maintenance and cleaning access.

01 / 05

Advantages

Pioneer in Dust Collection & Explosion Protection Solutions

Paphius quin etiam et Cornelius senatores, ambo venenorum artibus pravis se polluisse confessi, eodem pronuntiante

24/7 Online Support

We offer 24/7 online support to assist with all your Power Supply needs.

Reduce High Equipment
Failure Rate

Conductive dust intrusion into precision equipment causes frequent breakdowns and downtime

Environmental Protection And Compliance Pressure

Strict environmental protection regulations and safety production access requirements.

Specification

Tech Specs

	DT-2-4-HC	DT-2-6-HC	DT-2-8-HC	DT-3-9-HC	DT-3-12-HC
Power (kW)	5.5	7.5	11	11或15	18.5
Power Supply (V/Hz)	380/50	380/50	380/50	380/50	380/50
Max. Airflow (m³/h)	5000	7000	8500	10000	15000
Filter Area (m²)	80	120	160	180	240
Cartridge Quantity (pcs)	4 (Ahlstrom)	6 (Ahlstrom)	8 (Ahlstrom)	9 (Ahlstrom)	12 (Ahlstrom)
Cartridge Dimensions	350*660	350*660	350*660	350*660	350*660
Dust Bin Volume (L)	50	50	110	95	100
Noise Level dB(A)	84±2	86±2	88±2	88±2	90±2
Dimensions (cm)	106122195	106122240	106198208	149124250	195013002750
Negative Pressure (Pa)	3500	4000	5000	5000	7000
Other Configurations	Frequency Converter, PLC, Touch Screen, etc. Optional sensors: Air velocity sensor, Differential pressure switch, Dust concentration detector

Case Study

Dust Removal In Electrode Workshop
- Challenge: Humidity in the workshop must be kept below 1%, and NCM811 cathode material is highly explosive.
- Solution: Anti-static filter cartridges, explosion-proof valves, and a spark detection and extinguishing system are used throughout.
- 48%
  Dust concentration
- 63%
  Safety Incidents
Case Study

Dust Removal In Electrode Workshop
- Challenge: Humidity in the workshop must be kept below 1%, and NCM811 cathode material is highly explosive.
- Solution: Anti-static filter cartridges, explosion-proof valves, and a spark detection and extinguishing system are used throughout.
- 48%
  Dust concentration
- 63%
  Safety Incidents
Case Study

Dust Removal In Electrode Workshop
- Challenge: Humidity in the workshop must be kept below 1%, and NCM811 cathode material is highly explosive.
- Solution: Anti-static filter cartridges, explosion-proof valves, and a spark detection and extinguishing system are used throughout.
- 48%
  Dust concentration
- 63%
  Safety Incidents
